Hitachi RX User Manual

5-1 ●Maintenance
Maintenance menu 2015.07.0712:45
Back
Com=0
[Ready ]
Unit information
Operation
management
Test print
Excitation V update
(Nozzle test)
View alarm
history
Circulation control
View software
version
Comm. monitor
Password
protection
M
Manual
HOME
Shutdown
Solenoid valve/
pump test
(1) Functions
5. MAINTENANCE
Item Description Reference
Unit information ●Displays the unit TYPE-FORM, serial number, etc. 5.1
Operation management ●Displays the operational status. 5.2
Test print ●Prints without any start print signal input. 5.3
Excitation V update
(Nozzle test)
●Finds the optimum excitation V-ref. value to
maintain good print quality.
Technical Manual
6.10
View alarm history
●Displays the generation status of error and alarm
messages.
9.3
Circulation control ●Controls the ink and makeup circulation system. Technical Manual 6
View software version ●Displays the name of the registered software. 5.4
Comm. monitor
●Displays the description of the serial
communications between an external device and the
IJ printer.
Technical Manual
5.6
Password protection ●Displays the functions that can be executed. 5.5
Solenoid valve / pump
test
●Checks the operation of the solenoid valve and
pump.
Technical Manual
6.13
(2) Operation
Press Maintenance in the Print description screen.
The maintenance menu screen is displayed.
1
