●Specifications 12-1
12. SPECIFICATIONS
Item
Model
RX-SD160W, RX-SD160S RX-BD160W, RX-BD160S
Nozzle size 65μm
Max. print line number
Up to 2 lines
(OP: Up to 4 lines)
Up to 2 lines
Maximum number of print
characters
Up to 120 characters
(OP: Up to 1000 characters)
Up to 60 characters
Font
4x5 Option: V -
5x5 V V
5x7(8),9x7(8) V V
7x10 V V
10x12 V V
12x16 V V
18x24 Option: V -
24x32 Option: V -
Character height 2-10 mm / 0.08-0.39 inches
Display & input device
WYSIWYG design; Display: TFT LCD (10.4" color), backlight provided;
Input device: Touch panel, input sound provided
Maximum print rate
(character per second)
(Font 5x5, space 1, 1line)
Up to 1,256
(OP: Up to 2,513)
Up to 837
Standard characters Alphanumeric (A-Z, a-z, 0-9), symbols (27), space : Total 90
User pattern Each dot matrix 200 patterns Each dot matrix 50 patterns
Print functions Calendar, Count, Font mixture, Passwords security, etc.
Barcode printing
code39, ITF, NW-7, EAN-13, EAN-8, UPC-A,
UPC-E, code128/EAN-128
-
2D code printing OP: Data Matrix , QR code -
Message storage capacity
48 messages
(Op: Up to 2000 messages
(depends on data content))
24 messages
Input signal
Print target detection, Rotary encoder pulse,
Printing stop, Reciprocative printing,
Remote control (Run, Stop, High-voltage ON/
OFF, Reset)
(NPN/PNP Selectable)
Print target detection, Rotary encoder pulse
(NPN/PNP Selectable),
OP:Printing stop,
Reciprocative printing,
Remote control (NPN/PNP Selectable)
Output signal
Print ready, Fault, Warning (NPN Only),
Print in progress or Print complete,
Online (NPN/PNP Selectable)
Print ready, Fault, Warning (NPN Only),
OP:Print in progress or Print complete,
Online (NPN/PNP Selectable)
Data interface RS-232C
RS-232C at baud rates selectable up to
115,200bps
Option
(RS-232C at baud rates selectable up to
115,200bps)
External memory USB for user data storage
Head cable length, angle 4m / 13.1ft, inline / 90 degrees
Operating temperature range 0-45ºC / 32-113ºF (JP-K67, JP-K69 Ink)
Humidity range 30-90% R.H. (No condensation)
Power supply
(Automatic voltage selection)
AC100-120/220-240V±10% 50/60Hz 150VA (AC Inlet)
Corrosive gas There must be no corrosive gas
Overall size
(Width x Depth x Height)
400x340x480mm / 15.7x13.4x18.9 inches
Approximate weight 25kg / 55lbs
