●Main body internal parts arrangement 2-2
(2) External views (rear side)
2.2 Main body internal parts arrangement
Air-purge
connection port
Exhaust duct
connection port
Makeup
reservoir
Ink reservoir
Maintenance
cover
Makeup filter
Recovery filter
Pressure-reducing
valve
Ink filter
Main ink tank
