Hitachi RX User Manual

4-22 ●Set the print format
4.7.5 Print a bar code (RX-S only)
(1) Kinds of bar codes
●Different kinds of bar codes can be set for each print item.
Kinds of bar codes
Bar code Kinds of characters which can be input Remarks
Code 39
0 to 9 A to Z Space
+ - (minus) / . (period) $ %
ITF 0 to 99 Input of two-digit numbers
NW-7
0 to 9
+ - (minus) / . (period) : (colon) $
EAN-13 0 to 9
EAN-8 0 to 9
UPC-A 0 to 9
UPC-E 0 to 9
Code 128
(code set B)
0 to 9 A to Z a to z Space
FNC1 Code B Code C Symbols
Input numerics of two-digit
numbers
Code 128
(code set C)
0 to 9 FNC1 Code B Code C
Data matrix
(DM)
0 to 9 A to Z a to z Space
FNC1 Symbols
QR code Same as above.
●When a bar code of the same kind was set at adjacent print items, only the continuous series bar code is
assumed. However, fixed length bar codes such as EAN-13, EAN-8, UPC-A and UPC-E become
independent bar codes.
●For multiple settings, provide a print item for which a bar code is not set between the print items with a
bar code set.
●Up to a maximum of 4 DM (Data Matrix) , code 128 and QR code can be set respectively.
●Since the number of horizontal dots is uniquely determined for bar codes, an inter-character space cannot
be set.
●A bar code can be set even for print items with a calendar and count set. However, when calendar
substitution, zero suppression, or an invalid character is set, for the bar code setting, the relevant character
is deleted.
●When code set C of code 128 was set when the English alphabet is set for the count upper limit, the
relevant character is deleted.
●Since start and stop codes are automatically generated, input as print description is unnecessary.
See the Technical Manual for details.
