Hitron CVE-30360 User Manual

55
HITRON CVE-30360 USER’S GUIDE
FIREWALL
FIGURE 17: The Firewall > IP Filtering > Add/Edit Screen
The following table describes the labels in this screen.
TABLE 17: The Firewall > IP Filtering > Add/Edit Screen
Application Name Enter a name for the application that you want to block.
NOTE: This name is arbitrary, and does not affect
functionality in any way.
Port Range Use these fields to specify the target port range to which
communication should be blocked.
Enter the start port number in the first field, and the end
port number in the second field.
To specify only a single port, enter its number in both
fields.
Protocol Use this field to specify whether the CVE-30360 should
block communication via:
 Transmission Control Protocol (TCP)
 User Datagram Protocol (UDP)
 Both TCP and UDP.
NOTE: If in doubt, leave this field at its default (Both).
IP Address Range Use these fields to specify the range of local computers’
IP addresses from which communications should be
blocked.
Enter the start IP address in the first field, and the end IP
address in the second.
To specify only a single IP address, enter it in both fields.
Connected Computers Click this to see a list of the computers currently
connected to the CVE-30360 on the LAN.
Back Click this to return to the Firewall > IP filtering screen
without saving your changes to the IP filtering rule.
Apply Click this to save your changes to the fields in this
screen.
