17
CONTROLS AND FEATURES
Steering Friction Bolt
The steering friction bolt adjusts
steering resistance.
Less friction allows the outboard
motor to turn more easily
. More
friction helps to hold a steady course
while cruising or to prevent the
outboard motor from swinging while
trailering the boat.
Clamp Screws
Use the clamp screws to secure the
outboard motor to the transom.
Fuel Filler Cap Vent Knob
The fuel filler cap is provided with a
vent knob to seal the fuel tank. Open
the vent by turning the vent knob ON
position before starting the engine
(p. 25).
STEERING FRICTION BOLT
TO INCREASE
FRICTION
TO DECREASE
FRICTION
CLAMP SCREWS
VENT KNOB
OPEN
FUEL FILLER CAP
31ZW66320.book 17 ページ ２０１３年１０月４日 金曜日 午後３時４８分
