18
CONTROLS AND FEATURES
OTHER FEATURES
Centrifugal Clutch
The centrifugal clutch automatically
engages and transmits power when
engine speed is increased above
approximately 2,700 rpm. At idle
speed, the clutch is disengaged.
Oil Level Inspection Window
Use the oil level inspection window
to check the engine oil level with the
engine stopped and the outboard
motor in the upright position.
Anode
The anode is made of a sacrificial
material that helps to protect the
outboard motor from corrosion.
LOWER
LIMIT
UPPER
LIMIT
OIL LEVEL INSPECTION WINDOW
ANODE
Short shaft type
Long shaft type
31ZW66320.book 18 ページ ２０１３年１０月４日 金曜日 午後３時４８分
