42
SERVICING YOUR OUTBOARD MOTOR
ENGINE COVER REMOVAL
AND INSTALLATION
The engine cover retaining strap
fastens the engine cover to the
outboard motor.
To remove the engine cover, unhook
th
e engine cover retaining strap, then
lift the engine cover off the outboard
motor.
To install the engine cover, place the
cover on the outboard
motor, then
hook the engine cover retaining strap
securely.
Engine Oil Level Check
Check the engine oil level with the
engine stopped and the outboard
motor in the vertical position.
1. Check the oil level shown on the
oil
level inspection window.
2. If the oil level is near or below the
lower limit mark on the window
,
fill with the recommended oil to
the upper limit mark on the
window.
Running the engine with a low oil
level can cause engine damage.
ENGINE COVER
STRAP
OIL LEVEL INSPECTION WINDOW
UPPER
LIMIT
LOWER
LIMIT
31ZW66320.book 42 ページ ２０１３年１０月４日 金曜日 午後３時４８分
