20
INSTALLATION
When the outboard motor is installed
extremely low, water may enter into
the engine under case and negatively
affect the performance and durability.
When installing, check that the
outboard motor is high enough from
the water level to keep the engine
under case from waves, splash, etc.
when the engine is stopped with the
boat fully loaded.
If the outboard motor is installed too
low
, the boat will squat and be hard to
plane, and the outboard motor will
spray water that may enter the boat. It
will tend to porpoise, and high-speed
stability will be reduced.
Propeller ventilation will occur if the
outboard
motor is installed too high
on the boat transom.
Optimum installation height varies
with boat type a
nd bottom shape.
Contact the boat manufacturer for any
special recommendations that are
unique to a specific model of boat.
If the transom needs to be modified to
acc
ommodate the outboard motor,
contact the boat manufacturer and
follow their recommendations for
corrective action.
ATTACHMENT
Attach the stern bracket to the boat
transom by tightening the clamp
screws.
Attach a rope from the boat to the
hole in the stern
bracket. This will
help to prevent accidental loss of the
outboard motor.
CLAMP SCREWS
STERN BRACKET
SAFETY ROPE
31ZW66320.book 20 ページ ２０１３年１０月４日 金曜日 午後３時４８分
