TECHNICAL INFORMATION
Specifications
Tuneup
MODEL BF2.3D
Description code BAVJ
Type SCH LCH
Overall length 16.1 in (410 mm)
Overall width 11.2 in (285 mm)
Overall height 38.0 in (964 mm) 44.0 in (1,117 mm)
Transom height
(when transom
angle at 5°)
16.5 in (418 mm) 22.5 in (571 mm)
Dry mass [weight]* 30.0 lbs (13.6 kg) 31.5 lbs (14.3 kg)
Rated power 1.7 kW (2.3 HP)
Full throttle range 5,000 – 6,000 rpm
Engine type 4 stroke OHV 1 cylinder
Displacement
3.49 cu-in (57.2 cm
3
)
Spark plug gap 0.024 – 0.028 in (0.6 – 0.7 mm)
Starter system Recoil starter
Ignition system Transistorized magneto
Lubrication system Oil slinger system
Specified oil Engine:
SAE/FC-W 10W-30
Gear case:
Hypoid gear oil
Oil capacity Engine:
Gear case:
CARB star label ULTRA LOW EMISSION
Cooling system Engine: Forced air cooling
Exhaust system Underwater exhaust
Spark plug CR4HSB (NGK)
U
14FSR-UB (DENSO)
Fuel Unleaded gasoline
(8
6 pump octane or higher)
Tank capacity 0.29 US gal (1.1 L)
Steering equipment Tiller handle
Steering angle 360°
Transom angle 4 stages (5°, 10°, 15°, 20°)
Tilt up angle
(when transom
angle at 5°)
75°
Clutch system Centrifugal clutch
Spark plug gap 0.024 – 0.028 in
(
0.6 – 0.7 mm)
See page 47
Idle speed 2,000 ± 100 rpm See shop
ma
nual
Valve clearance
(cold)
Intake:
Exhaust:
See shop
ma
nual
Other specifications No other adjustment is needed
0.26 US qt (0.25 L)
0.05 US qt (0.05 L)
API standard (SG, SH or SJ oil)
API standard (GL-4) SAE 90
0.08 ± 0.02 mm
0.11 ± 0.02 mm
* With propeller
Honda outboard motors are power rated in accordance with NMMA procedures and using the ICOMIA standard 28/23.
