Advanced CIU 888 Settings
Part No.: 4417593_Rev09 Ensite Pro to CIU 888 Migration Manual
CIU 888 6 - 1
CHAPTER 6 ADVANCED CIU 888 SETTINGS
6.1 Setting the date and time of the CIU 888
The date and time of the CIU 888 can be configured during
commissioning/configuration of the CIU 888. Subsequently, the date
and time are set when the site configuration is uploaded to the CIU 888.
To set the date and time, the CIU 888 must be connected to the PC/
laptop running Ensite Pro (part of the CIU 888 Configuration System)
via:
Service port located at the front of the CIU 888 using a Cat. 5
Ethernet cable (see FIGURE 6-1)
FIGURE 6-1 CIU 888: Service port
and
One of the serial host ports located at the back of the CIU 888 using
a serial cable (see FIGURE 6-2)
FIGURE 6-2 CIU 888: serial host ports
Furthermore, communication between the CIU 888 and Ensite Pro
system must be established.
