Product Description SmartRadar FlexLine
Part No.: 4417.760_Rev06 Installation Guide
15
3.3 SmartView
3.3.1 Function
The SmartView display can be part of the device. You can install
it as stand alone version as well. In this case it is placed in a
larger housing. Refer to the display installation guide.
3.4 SmartConn
3.4.1 Function
SmartConn is an optional Ex-e junction box and is only certified
for ATEX, IEC Ex and CSA. It simplifies the external connection
of the device and provides additional cable entries.
3.4.2 Components
FIG. 3-3 Optional Ex-e junction box components
H Separator coupling (connection between antenna and SmartRadar Flex-
Line)
I FlexConn box
J Inner cover (do not open, do not touch), tampering label
Description (see FIG. 3-2)
A
E
B
C
D
