Honeywell Enraf SmartRadar FlexLine User Manual

Installation SmartRadar FlexLine
Part No.: 4417.760_Rev06 Installation Guide
33
4.11.3.2 Enraf Fieldbus (BiPhase Mark)
4.11.3.2.1 Topology
A maximum of 10 devices can be connected to the Enraf field
bus line.
NOTE:
The DC polarity is not critical.
NOTE:
Install an explosion proof mains switch in the mains
cable to the SmartRadar.
Cable specifications
Type Suitable for the SmartRadar power rating, and approved
for use in hazardous areas
Label Parameters
00. Vin-a/L 24-65 Vdc -15/+10%
65-240 Vac -15/+10%
50/60 Hz ± 10%
Automatic selection
01. Vin-b/N
Cable specifications
Type Twisted pair; R
max
= 200 Ohm /line, C
max
= 1 μF.
Maximum length 10 km
Label Parameters
06. TL1 1200/2400/4800 bps
Selection by software
07. TL2
