Periphery components for ESSER FACP
34 TI 798960.GB0 / 04.20
6.2 Manual call points - large design (aluminium Die-Cast Housings)
Manual call points are combined from electronic module and housing.
Fig. 20: Manual call points aluminium Die-Cast Housings
Part No. Description
704477.10 Electronic module with 2 micro switches
804473.10 Electronic module Intelligent fire detector (IFD) with zone isolator
Accessories
701040 Glass panel replacements acc. DIN 14655/G for MCP housing 7047xx and 7048xx
704910 Glass panel replacements acc. EN 54-11 for MCP housing 70490xx, 7048xx and 761694
Plastic sign "not in operation"
781682 Weather-proof housing, red for manual call point housing 7048xx
781692 Weather-proof housing, blue for manual call point housing 7048xx
Cable fittings to increase the IP rating from IP 43 to IP 54
704801.10
Housing with glass plane, printed with pictograms, acc. EN 54-11, red
(similar to RAL 3000)
704801.11
Manual call point housing Aluminium Die-Cast, printed with pictograms and Feuerwehr,
acc. EN 54-11, red (similar to RAL 3000)
Housing with glass plane, printed with house alarm ESSER, red (similar to RAL 3000)
704854 Housing with glass plane, printed with house alarm ESSER, blue (similar to RAL 5009)
704874 Housing with glass plane, printed with house alarm ESSER, yellow (similar to RAL 1018)
Housing with glass plane, neutral without pictograms, red (similar to RAL 3000)
Housing with glass plane, neutral without pictograms, blue (similar to RAL 5009)
704870 Housing with glass plane, neutral without pictograms, yellow (similar to RAL 1018)
704890 Housing with glass plane, neutral without pictograms, grey (similar to RAL 7035)
