Honeywell Genesis 7580G User Manual

10 - 2
Test Menu
When you scan the Test Menu On code, then scan a programming code in this manual, the scanner displays the content of a
programming code. The programming function will still occur, but in addition, the content of that programming code is output to
the terminal.
Note: This feature should not be used during normal scanner operation.
TotalFreedom
TotalFreedom is an open system architecture that makes it possible for you create applications that reside on your scanner.
Decoding apps and Data Formatting apps can be created using TotalFreedom. For further information about TotalFreedom, go
to our website at
www.honeywellaidc.com.
Application Plug-Ins (Apps)
Any apps that you are using can be turned off or on by scanning the following bar codes. Apps are stored in groups: Decoding,
and Formatting. You can enable and disable these groups of apps by scanning that group’s On or Off bar code below. You can
also scan the List Apps bar code to output a list of all your apps.
Note: You must reset your device in order for the apps setting to take effect.
On
* Off
* Decoding Apps On
Decoding Apps Off
* Formatting Apps On
Formatting Apps Off
List Apps

Honeywell Genesis 7580G Specifications

General

Type	Fixed bar code reader
Sensor type	-
Scanner type	1D/2D
Pitch reading angle	-70 - 70 °
Motion tolerance (cm/s)	200
Light levels (direct sunlight)	0 - 100000 lx
Standard interfaces	USB, RS-232, RS-485, Keyboard wedge
Product color	Black, Silver
Input voltage	5.5 V
Power consumption (standby)	0.5 W
Power consumption (typical)	2 W
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	80 mm
Width	83 mm
Height	150 mm
Weight	340 g
