Honeywell Genesis 7580G User Manual

3 - 7
Presentation LED Behavior after Decode
When a scanner is in presentation mode, the LEDs dim 30 seconds after a bar code is decoded. If you wish to dim the
LEDs immediately after a bar code is decoded, scan the LEDs Off bar code, below. Default = LEDs On.
Presentation Sensitivity
Presentation Sensitivity is a numeric range that increases or decreases the scanner's reaction time to bar code presenta-
tion. To set the sensitivity, scan the Sensitivity bar code, then scan the degree of sensitivity (from 0-20) from the inside
back cover, and Save. 0 is the most sensitive setting, and 20 is the least sensitive. Default = 1.o
Presentation Centering
Use Presentation Centering to narrow the scanner’s field of view when it is in Presentation Mode to make sure the scanner
reads only those bar codes intended by the user. For instance, if multiple codes are placed closely together, Presentation
Centering will insure that only the desired codes are read.
Note: To adjust centering when the scanner is hand-held, see Presentation Aimer Mode (page 3-12).
If a bar code is not touched by a predefined window, it will not be decoded or output by the scanner. If Presentation Center-
ing is turned on by scanning Presentation Centering On, the scanner only reads codes that pass through the centering
window you specify using the Top of Presentation Centering Window, Bottom of Presentation Centering Window,
Left, and Right of Presentation Centering Window bar codes.
* LEDs On
LEDs Off
Sensitivity

Honeywell Genesis 7580G Specifications

General

Type	Fixed bar code reader
Sensor type	-
Scanner type	1D/2D
Pitch reading angle	-70 - 70 °
Motion tolerance (cm/s)	200
Light levels (direct sunlight)	0 - 100000 lx
Standard interfaces	USB, RS-232, RS-485, Keyboard wedge
Product color	Black, Silver
Input voltage	5.5 V
Power consumption (standby)	0.5 W
Power consumption (typical)	2 W
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	80 mm
Width	83 mm
Height	150 mm
Weight	340 g
