Honeywell Genesis 7580G User Manual

A - 7
ISO 2022/ISO 646 Character Replacements
Code pages define the mapping of character codes to characters. If the data received does not display with the proper charac-
ters, it may be because the bar code being scanned was created using a code page that is different from the one the host pro-
gram is expecting. If this is the case, select the code page with which the bar codes were created. The data characters should
then appear properly.
227 E3 ã π
228 E4 ä Σ
229 E5 å σ
230 E6 æµ
231 E7 ç τ
232 E8 è Φ
233 E9 é Θ
234 EA ê Ω
235 EB ë δ
236 EC ì ∞
237 ED í φ
238 EE î ε
239 EF ï ∩
240 F0 ð ≡
241 F1 ñ±
242 F2 ò ≥
243 F3 ó ≤
244 F4 ô ⌠
245 F5 õ ⌡
246 F6 ö÷
247 F7 ÷ ≈
248 F8 ø°
249 F9 ù ·
250 FA ú·
251 FB û √
252 FC ü ⁿ
253 FD ý²
254 FE þ ■
255 FF ÿ
Code Page Selection Method/Country Standard Keyboard Country Honeywell Code Page
Option
United States
(standard ASCII)
ISO/IEC 646-IRV n/a 1
Automatic National Character
Replacement
ISO/IEC 2022 n/a 2 (default)
Binary Code page n/a n/a 3
Default “Automatic National Character replacement” will select the below Honeywell Code Page options for Code128, Code
39 and Code 93.
United States ISO/IEC 646-06 0 1
Canada ISO /IEC 646-121 54 95
Canada ISO /IEC 646-122 18 96
Japan ISO/IEC 646-14 28 98
Extended ASCII Characters (Continued)
DEC HEX CP 1252 ASCII Alternate Extended PS2 Scan Code

Honeywell Genesis 7580G Specifications

General

Type	Fixed bar code reader
Sensor type	-
Scanner type	1D/2D
Pitch reading angle	-70 - 70 °
Motion tolerance (cm/s)	200
Light levels (direct sunlight)	0 - 100000 lx
Standard interfaces	USB, RS-232, RS-485, Keyboard wedge
Product color	Black, Silver
Input voltage	5.5 V
Power consumption (standby)	0.5 W
Power consumption (typical)	2 W
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	80 mm
Width	83 mm
Height	150 mm
Weight	340 g
