Honeywell Genesis 7580G User Manual

3 - 12
User-Specified Aimer Delay
If you want to set your own length for the duration of the delay, scan the bar code below, then set the time-out by scanning
digits (0 - 4,000 ms) from the Programming Chart inside the back cover of this manual, then scan Save.
Aimer Mode
This feature allows you to turn the aimer on and off while in a Manual Trigger Mode. When the Interlaced bar code is scanned,
the aimer is interlaced with the illumination LEDs. Default = Interlaced.
Presentation Aimer Mode
This feature allows you to turn the aimer on and off while the scanner is in Presentation Mode, Presentation - Mobile Phone,
Streaming Presentation Mode, or Streaming Presentation - Mobile Phone. When the Interlaced bar code is scanned, the aimer
is interlaced with the illumination LEDs. Default = Aimer Off.
Enhanced Object Detection
When in Enhanced Object Detection mode, the scan illumination remains on all the time to continuously search for bar codes.
When in Normal Object Detection mode, the scan illumination turns on while reading a bar code and is off when idle. Enhanced
mode offers better object detection sensitivity. Default = Enhance Object Detection.
Note: Enhanced Object Detection only works while in Presentation Mode (TRGMOD3) (page 3-6).
Delay Duration
Off
* Interlaced
Interlaced
*Off
Normal Object Detection

Honeywell Genesis 7580G Specifications

General

Type	Fixed bar code reader
Sensor type	-
Scanner type	1D/2D
Pitch reading angle	-70 - 70 °
Motion tolerance (cm/s)	200
Light levels (direct sunlight)	0 - 100000 lx
Standard interfaces	USB, RS-232, RS-485, Keyboard wedge
Product color	Black, Silver
Input voltage	5.5 V
Power consumption (standby)	0.5 W
Power consumption (typical)	2 W
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	80 mm
Width	83 mm
Height	150 mm
Weight	340 g
