Daily Operation
MAN0996_Iss 1_02/16 Touchpoint Plus
Pt. No. 3011M5044_EN 38 User Guide
4.14 Viewing and Exporting Event History
The event history for the complete system can be viewed in date order (latest first). The history can be filtered by Alarm,
Fault, Inhibit, or Warning.
4.14.1 To View the Event History
Touch Menu>Information>Event History, then touch the Filter icon of choice or scroll through the list.
Note: Touchpoint Plus does not adjust automatically for daylight savings time so it will retain a backup of the earlier data if
the clock is backdated (e.g. when ending daylight savings time).
Event data is automatically saved to an installed SD card. The event history data can also be exported to the SD card on
demand.
4.14.2 To Export the Event History
First touch the SD Card icon to ensure that you have sufficient empty space on the SD card.
Touch Menu>Information>Event History. Select the event (use filters if there are too many shown) and touch
Export Event.
Note: Microsoft Excel 2003 is limited to a maximum of 65,526 entries. If the report is larger than this a ‘file not loaded
completely’ message may be generated. Microsoft Excel 2010 has a much larger capacity that should be sufficient for all
Touchpoint Plus generated reports.
Note: Touchpoint Plus does not adjust automatically for daylight savings time so TPPL will retain a backup of the earlier
data if the clock is backdated (i.e. when ending daylight savings time).
4.15 Accessing the System Information and Service Contact Details
Touch Menu>Information>System information to view details about the Firmware, Software and serial
numbers.
Touch Menu>Information>Service Contact or see the back page for details of how to access technical
support.
4.16 System State and System Failure Relays
The Main Module has three relays (30 VDC or 250 VAC, both 1.7 A):
• One or both System State relays can activate if there is any active alarm, fault, warning or inhibit in the system (if
configured).
• The System Failure relay can activate if the safety function of the system is not operating, for example due to a major
fault or power loss.
