XNX Universal Transmitter Quick Start Guide
63
11 Warning Messages
Warning Description
Ap-
plicable
Sensors
Latching /
Non-Latching
Frequency of
Diagnostic
Event History
Data
Action For Resolution
W001
XNX 24 VDC
Supply Bad
All Non-latching 2 seconds
XNX supply
voltage x1000
Check wire of 24V power supply to XNX as well as power supply operation.
W002
XNX Tempera-
ture Error
All Non-latching 2 seconds
XNX tempera-
ture (Celsius)
Check location for heat sources. Fit with sunshade or other protection. Change
location of XNX. Check temperature in Info->Transmitter Status to ensure tem-
perature is being measured properly.
W003
Simulated Warn-
ing/Fault
All Non-latching
Enabled by
user
0 Performing an alarm/fault reset will clear all simulation.
W005
Sensor Tempera-
ture Error
Optima Non-latching
XNX polls
sensor every
2 seconds,
diagnostic
frequency
controlled by
sensor
Sensor fault or
warning code
(Note 4)
Check location for heat sources. Fit with sunshade or other protection. Change
location of XNX. Check temperature in Info->Sensor Status to ensure tempera-
ture is being measured properly.
Sensor Tempera-
ture Error
Excel Non-latching
XNX polls
sensor every
2 seconds,
diagnostic
frequency
controlled by
sensor
Sensor fault or
warning code
(Note 4)
Check location for heat sources. Fit with sunshade or other protection. Change
location of XNX. Check temperature in Info->Sensor Status to ensure tempera-
ture is being measured properly.
Sensor Tempera-
ture Error
ECC Non-latching 2 seconds
Sensor
temperature
(Celsius)
Check location for heat sources. Fit with sunshade or other protection. Change
location of XNX. Check temperature in Info->Sensor Status to ensure tempera-
ture is being measured properly.
