Example 4 Setting trusted ports
HP Switch(config)# dhcp-snooping trust 5-6
HP Switch(config)# show dhcp-snooping
DHCP Snooping Information
DHCP Snooping : Yes
Enabled Vlans : 4
Verify MAC : Yes
Option 82 untrusted policy : drop
Option 82 Insertion : Yes
Option 82 remote-id : mac
Store lease database : Not configured
Port Trust
----- -----
5 Yes
6 Yes
7 Yes
DHCP server packets are forwarded only if received on a trusted port; DHCP server packets received
on an untrusted port are dropped. Use the no form of the command to remove the trusted
configuration from a port.
Configuring authorized server addresses
If authorized server addresses are configured, a packet from a DHCP server must be received on
a trusted port AND have a source address in the authorized server list to be considered valid. If
no authorized servers are configured, all servers are considered valid. You can configure up to
20 authorized servers.
To configure a DHCP authorized server address, enter this command in the global configuration
context:
HP Switch(config)# dhcp-snooping authorized-server <ip-ad>
Example 5 Authorized servers for DHCP snooping
HP Switch(config)# show dhcp-snooping
DHCP Snooping Information
DHCP Snooping : Yes
Verify MAC : No
Option 82 untrusted policy : drop
Option 82 Insertion : Yes
Option 82 remote-id : subnet-ip
Authorized Servers
---------------------
111.222.3.4
10.0.0.11
Using DHCP snooping with Option 82
DHCP adds Option 82 (relay information option) to DHCP request packets received on untrusted
ports by default. (See “Configuring DHCP Relay” in the HP Switch Software Multicast and Routing
Guide for more information on Option 82.)
When DHCP is enabled globally and also enabled on a VLAN, and the switch is acting as a DHCP
relay, the settings for the DHCP relay Option 82 command are ignored when snooping controls
Option 82 insertion. Option 82 inserted in this way allows the association of the client’s lease
10 Updates for the HP Switch Software Access Security Guide
