A-2
Specifications
Environmental
1
If you are installing J8177Ctransceiver, the operating ambient temperature must not exceed 40°C
(104°F) and must not exceed 35°C (99°F), if FIPS Opacity Shield is installed.
When a J9830A PSU is installed, the temperature rating is reduced to 40°C
above 5,000 ft.
Acoustic
5406R zl2 Switch and its bundles:
Geräuschemission LpA = 31.7 dB am fiktiven Arbeitsplatz nach
DIN 45635 T.19
Noise Emission LpA = 31.7 dB in a virtual workspace according to
DIN 45635 T.19
5412R zl2 Switch and its bundles:
Geräuschemission LpA = 35.7 dB am fiktiven Arbeitsplatz nach
DIN 45635 T.19
Noise Emission LpA = 35.7 dB in a virtual workspace according to
DIN 45635 T.19
Operating Non-Operating
Temperature: 0°C to 45°C (32°F to 113°F)
1
-40°C to 70°C (-40°F to 158°F)
Relative humidity:
(non-condensing)
15% to 95% at 45°C (113°F) 15% to 95% at 65°C (149°F)
Maximum altitude: up to 3.1 km (10,000 ft) 4.6 km (15,000 ft)
