Table 6 International Three-Phase Power Specifications
Modular PDU 3-phaseiPDU 3-phaseR12000 3-phase UPSInternational
16 A/phase16 A/phase12 kWOutput Load
380-415V 3P Wye380-415V 3P Wye380-415V 3P WyeInput Voltage
IEC309 516P6IEC309 516P6IEC309 532P6Input Connector
N/AN/A400V 3P WyeOutput Voltage
6 x C19 (20 A)6 x C192 x IEC309 309 516C6Output Connectors
(42 x C13)(20 x C13)
UPS outputs are connected to the compatible PDU inputs.Notes
Enclosure AC Input for NS7 Systems
Enclosures (IP CLIM, SAS disk enclosure, and so forth) require:
ValueSpecification
200/208/220/230/240 V AC RMSNominal input voltage
180-264 V ACVoltage range
50 or 60 HzNominal line frequency
47-53 Hz or 57-63 HzFrequency ranges
1Number of phases
Single-phase c7000 enclosures require:
ValueSpecification
200-240 VACVoltage range
50 or 60 HzNominal line frequency
47-53 Hz or 57-63 HzFrequency ranges
1Number of phases
AC Input Power for NS7 Racks 47
