Rack Stability for NS7 Systems
Rack stabilizers are required when you have less than four racks bayed together.
NOTE: Rack stability is of special concern when equipment is routinely installed, removed, or
accessed within the rack. Stability is addressed through the use of leveling feet, baying kits, fixed
stabilizers, and/or ballast. Use baying kits to bay racks to racks of the same height. In all cases,
a rack cannot be bayed with another rack of a different height.
NOTE: For instructions on best practices for the Enterprise series rack (formerly known as the
Intelligent rack) or for using the HPE Rack Ground Bonding Kit (BW891A), ask your service
provider to see the instructions in the:
• HP Rack Options Installation Guide
• http://www.hpe.com/support/Intelligent_Series_Rack_Manuals.
Environmental Specifications for NS7 AC Systems
NS7 Heat Dissipation Specifications and Worksheet
Total (BTU/hour)Unit Heat (BTU/hour,
Maximum Heat
Dissipation)
Unit Heat
(BTU/hour, Typical
Heat Dissipation)
Number InstalledEnclosure Type
38562764c7000 enclosure
(single-phase)
785785BL460c Gen8 server
blade, 64GB
10241024BL460c Gen9 server
blade, 64GB
10751075BL460c Gen9 server
blade, 128GB
11261126BL460c Gen9 server
blade, 192GB
798706IB FDR ADI Switch
798706IB FDR I/O Expansion
Switch
798706IB FDR cluster switch
(NonStop X Cluster
Solution)
546444Gen8 Storage CLIM
529427Gen8 10GbE
Networking CLIM
4C/1C
511409Gen8 10GbE
Networking CLIM
4F/1C
10241024Gen9 Storage CLIM
631461Gen9 10GbE
Networking CLIM
4C/1C
Rack Stability for NS7 Systems 55
