A Cables
Cable Types and Connectors
Although a considerable cable length can exist between the modular enclosures in the system,
Hewlett Packard Enterprise recommends that cable length between each of the enclosures be
as short as possible.
The following table lists the available cables. For specific connections, see your system Technical
Document as described in Technical Document.
ConnectorsCable TypeConnection...
RJ-45 to RJ-45Ethernet CAT6AMaintenance LAN connections
RJ-45 ports on Networking CLIM to Patch
Panel
LC-LCMMF OM4Fiber Optic ports on Networking CLIM to Patch
Panel
Mini-SAS to HD SASSAS copperGen8 Storage CLIM to D3700 SAS disk
enclosure
SFF-8644 (HD) to
SFF-8644 (HD)
SAS copperGen9 Storage CLIM to D3700 SAS disk
enclosure
SFF-8644 (HD) to
SFF-8088
SAS copperCG Gen9 Storage CLIM to P2000 G4 SAS disk
enclosure
QSFPIB copperIB 4X FDR Cable
IB optical
80 Cables
