Figure 10-35. Example of Listing the ACL Assignments for Ports and Trunks
HP Switch(config)# show access-list ports all
Access Lists for Port B1
Inbound Ipv6: List-01-Inbound
Access Lists for Port B12
Inbound : 101
Type : Extended
Inbound Ipv6: Accounting
Access Lists for Port Trk2
Inbound Ipv6: Accounting
Access Lists for Port Trk5
Inbound : Marketing
Type : Extended
• An IPv6 ACL is filtering
inbound traffic on port B1.
• Both an IPv4 ACL and an IPv6
ACL are filtering inbound IPv4
and IPv6 traffic, respectively,
on port B12.
• An IPv6 ACL is filtering
inbound IPv6 traffic on Trunk 2
(Trk2).
• An IPv4 ACL is filtering
inbound IPv4 traffic on Trunk 5
(Trk5).
