v
Figure 57 Installing a slot divider
Figure 58 Installing filler panels
Replacing an HMIM
ARNING!
You can replace an HMIM when the router is powered on. However, before replacin
an HMIM when the
router is powered on, you must execute the remove hmimslot
slotnumber
command.
1. Completely loosen the captive screws of the HMIM.
2. Gently pull the HMIM out of the slot along the slide rails.
3. Install a new HMIM. For the installation procedure, see "Installing the router."
If you do not install a new HMIM, install a filler panel and tighten the screws.
