HP MSR2000 Series User Manual

iii
(4) RPS receptacle cover (5) Power switch
(6)
A
C-input power receptacle
(7) Power cord bail latch (8) SFP port (SFP0) (9) USB console port (CON)
(10) Console port/AUX port
(CON/AUX)
(11) Gigabit Ethernet port (GE2) (12) Gigabit Ethernet port (GE1)
(13) Gi
g
abit Ethernet port (GE0)
Figure 69 MSR3024 AC rear view
(1) Grounding terminal (2) SIC slot (slot 4) (3) SIC slot (slot 3)
(4) HMIM slot (slot 6) (5) HMIM slot (slot 5) (6) SIC slot (slot 1)
(7) SIC slot (slot 2)
MSR3024 DC
Figure 70 MSR3024 DC front view
(1) CF card cover (2) USB port 0 (3) USB port 1
(4) RPS receptacle cover (5) Power switch (6) DC-input power receptacle
(7) SFP port (SFP0) (8) USB console port (CON) (9) Console port/AUX port
(CON/AUX)
(10) Gi
g
abit Ethernet port (GE2) (11) Gi
g
abit Ethernet port (GE1) (12) Gi
g
abit Ethernet port (GE0)

HP MSR2000 Series Specifications

General

Brand	HP
Model	MSR2000 Series
Category	Network Router
Language	English
