HP MSR2000 Series User Manual

iv
Figure 71 MSR3024 DC rear view
(1) Groundin
g
terminal (2)SIC slot (slot 4) (3) SIC slot (slot 3)
(4) HMIM slot (slot 6) (5) HMIM slot (slot 5) (6) SIC slot (slot 1)
(7) SIC slot (slot 2)
MSR3024 PoE
Figure 72 MSR3024 PoE front view
(1) CF card cover (2) USB port 0 (3) USB port 1
(4) RPS receptacle cover (5) Power switch (6) AC-input power receptacle
(7) Power cord bail latch (8) SFP port (SFP0) (9) USB console port (CON)
(10) Console port/AUX port
(CON/AUX)
(11) Gigabit Ethernet port (GE2) (12) Gigabit Ethernet port (GE1)
(13) Gigabit Ethernet port (GE0)
Figure 73 MSR3024 PoE rear view
(1) Groundin
g
terminal (2)SIC slot (slot 4) (3) SIC slot (slot 3)
(4) HMIM slot (slot 6) (5) HMIM slot (slot 5) (6) SIC slot (slot 1)
(7) SIC slot (slot 2)
