MSR3044
Figure 83 MSR3044 LEDs
(1) CF card LED (2) System LED (SYS) (3) Power supply LED (PWR)
(4) PoE power supply LED (5) VPM (slot 0) LED (VPM0) (6) VPM (slot 1) LED (VPM1)
(7) Gigabit Ethernet port LED (GE0) (8) SFP port LED (SFP0) (9) Gigabit Ethernet port LED (GE1)
(10) SFP port LED (SFP1) (11) Gigabit Ethernet port LED
(GE2)
(12) Console port LED
(13) USB console port LED
MSR3064
Figure 84 MSR3064 LEDs
(1)CF card LED (2) System LED (SYS) (3) Power supply LED (PWR)
(4) PoE power supply LED (5) VPM (slot 0) LED (VPM0) (6) VPM (slot 1) LED (VPM1)
(7) Gi
g
abit Ethernet port LED (GE0) (8) SFP port LED (SFP0) (9) Gi
g
abit Ethernet port LED (GE1)
(10) SFP port LED (SFP1) (11) Gigabit Ethernet port LED
(GE2)
(12) Console port LED
(13) USB console port LED
