Access Panel

Description Spare part number

Access panel 657104-001

1. Prepare the computer for disassembly (Preparation for Disassembly on page 42).

2. Using a flathead or Torx screwdriver, remove the screw on the back panel that secures the

panel to the computer.

Figure 7-1 Removing the access panel screw

Access Panel 43

Other manuals for HP Pro 3330

Need help?

Do you have a question about the HP Pro 3330 and is the answer not in the manual?

General

Chipset	Intel H61 Express
Power Supply	300W
Processor	Intel Core i3-2120
Memory	Up to 8 GB DDR3-1333 SDRAM
Storage	500GB 7200 rpm SATA
Graphics	Integrated Intel HD Graphics
Operating System	Windows 7 Professional
Optical Drive	DVD Writer
Audio	Integrated High Definition Audio
Network	Integrated 10/100/1000 Ethernet
Ports	6 USB 2.0, 1 VGA, 1 RJ-45
