C-7
Hardware Components
Replacing the Flash Card
9. Re-install the module into the switch.
10. Use an equal amount of pressure and push both extractor handles closed
to completely seat the module.
11. Tighten the retaining screws.
Figure C-5. Steps to Replacing the Module’s Disk Drive
Replacing the Flash Card
The following is the procedure for replacing the Flash Card in the Services
Module. The module may be removed while the switch is powered on. The
numbers in Figure C-6 correspond to the step numbers below.
1. 2.
3. 4.
