Removal and replacement procedures
Tablet component replacement procedures
CAUTION: Tablet components described in this chapter should only be accessed by an authorized
service provider. Accessing these parts can damage the tablet and void the warranty.
This chapter provides removal and replacement procedures for authorized service provider only parts.
There are as many as 29 screws that must be removed, replaced, and/or loosened when servicing the
tablet. Make special note of each screw size and location during removal and replacement.
Back cover
Description Spare part number
Back cover (includes internal shielding) 736881-001
Display assembly:
NOTE: The display assembly does not include the display assembly cable. The display assembly cable is included in the
Cable Kit, spare part number 736883-001. See
Cable Kit on page 21 for more Cable Kit spare part information.
13.3-inch, AG, FHD, WLED TouchScreen, display assembly 737696-001
13.3-inch, AG, HD, WLED TouchScreen, display assembly 737697-001
Before disassembling the tablet, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
Remove the back cover:
1. Place the tablet on a flat surface, display screen side up, with the docking connector, power
connector, and audio connector toward you.
34 Chapter 4 Removal and replacement preliminary requirements
