Audio/power connector board
Description Spare part number
Aiudio/power connector board
NOTE: The audio/power connector board does not include the audio/power connector board
cable. The audio/power connector board cable is included in the Cable Kit, spare part number
736883-001. See
Cable Kit on page 21 for more Cable Kit spare part information.
736887-001
Before removing the audio/power connector board, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see
Back cover on page 34).
5. Remove the tablet battery (see
Tablet battery on page 36).
Remove the audio/power connector board:
1. Release the audio/power connector board ZIF connector (1) to which the NFC module cable is
attached, and then disconnect the NFC module cable from the audio/power connector board.
2. Release the system board ZIF connector (2) to which the audio/power connector board cable is
attached, and then disconnect the audio/power connector board cable from the system board.
3. Disconnect the speaker cable (3) from the audio/power connector board.
4. Remove the two Phillips PM2.0×3.0 screws (4) that secure the audio/power connector board to
the display assembly.
Removal and replacement procedures
51
