HP Z240 User Manual

Initial computer conguration and deployment
The computer includes a preinstalled system software image. After a brief software unbundling process, the
computer is ready to use.
If you prefer to replace the preinstalled software image with a customized set of system and application
software, you can deploy a customized software image by:
●
Installing additional software applications after unbundling the preinstalled software image
●
Using a disk-cloning process to copy the contents from one hard drive to another
The HDD-based HP Recovery Manager ROM-based setup, and ACPI hardware provide further assistance with
recovery of system software, conguration management and troubleshooting, and power management.
Support for specic features described in this guide can vary by model and software version.
The best deployment method depends on the information technology environment and processes.
Installing a remote system
Remote system installation enables starting and setting up the computer using software and conguration
information on a network server. This feature is usually used for system setup and conguration and can be
used to:
●
Deploy a software image on new PCs
●
Format a hard drive
●
Install application software or drivers
●
Update the operating system, application software, or drivers
To initiate a remote system installation, press f12 when f12=Network Service Boot appears in the lower-
right corner of the HP logo screen. Follow the on-screen instructions to continue the installation process. The
default boot order is a BIOS conguration setting that can be changed to always attempt a network boot.
Copying a setup conguration to another computer
This section provides information about replicating the computer setup.
CAUTION: Setup conguration is model-specic. File system corruption can result if source and target
computers are not the same model.
To copy a setup conguration:
1. Select a setup conguration to copy, and then restart the computer.
2. As soon as you start or restart the computer, press and hold F10 until you enter Computer Setup (F10)
Utility. If necessary, press enter to bypass the title screen.
NOTE: If you do not press F10 at the appropriate time, you must restart the computer, and then press
and hold F10 again to access the utility.
If you are using a PS/2 keyboard, you might see a keyboard error message. Disregard it.
3. Select Main > Replicated Setup > Backup current settings to USB device. Follow the instructions on the
screen to create the conguration le cpqsetup.txt and write it to a USB storage device.
4. Turn o the computer you are conguring and insert the removable USB media device containing the
conguration le.
30 Chapter 2 System management

HP Z240 Specifications

General

Chassis type	Tower
Product color	Black
Country of origin	China
Water cooling system	No
Product type	Workstation
Motherboard chipset	Intel® C236
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	64 GB
Memory layout (slots x size)	2 x 4 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	-
Total storage capacity	1000 GB
Number of HDDs installed	1
On-board graphics card ID	0x191D
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics P530
Graphics card Open GL support	Yes
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Power supply	400 W
Recovery operating system	Windows 10 Pro
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
Tcase	- °C
Bus type	DMI3
Stepping	R0
Processor cache	8 MB
Processor model	E3-1245V5
System bus rate	8 GT/s
Processor series	Intel Xeon E3-1200 v5
Processor socket	LGA 1151 (Socket H4)
Processor threads	8
Processor codename	Skylake
Processor frequency	3.5 GHz
Processor cache type	Smart Cache
Configurable TDP-down	- W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.9 GHz
PCI Express configurations	1x16, 1x8+2x4, 2x8
Thermal Design Power (TDP)	80 W
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Scalability	1S
Processor ARK ID	88173
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Secure Key Technology version	1.00

Weight and Dimensions

Depth	442 mm
Width	170 mm
Height	399 mm
Weight	8600 g
