Problem Cause Solution
OR
The processor heatsink fan
assembly is not properly
attached to the processor.
3. Verify that the system fan is running.
4. Verify that the processor heatsink fan spins.
If the heatsink fan is not spinning, verify that the fan
cable is plugged into the system board connector. Verify
that the fan is properly seated.
5. Replace the processor heatsink.
Power LED ashes red (once every 2
seconds).
Power failure (power supply is
overloaded).
1. Determine whether a device is causing the problem by
performing the following:
a. Disconnect AC power.
b. Remove all attached devices.
c. Turn on the workstation.
If the system enters the POST, perform the following:
a. Power o the workstation.
b. Replace one device at a time and repeat this
procedure until a failure occurs.
c. Replace the device causing the failure.
d. Continue adding devices one at a time to verify
that all devices are functioning.
2. Verify power supply functionality (Tower only).
a. Disconnect AC power.
b. Unplug all system board power cables.
c. Plug in AC power.
●
If the PSU fan spins and the LED is
illuminated (see Testing power supply
on page 72), the power supply is good.
Replace the system board.
●
If the PSU fan does not spin or the LED does
not illuminate (see Testing power supply
on page 72), replace the power supply.
Using HP PC Hardware Diagnostics (UEFI)
HP PC Hardware Diagnostics is a Unied Extensible Firmware Interface (UEFI) that allows you to run diagnostic
tests to determine whether the computer hardware is functioning properly. The tool runs outside the
operating system so that it can isolate hardware failures from issues that are caused by the operating system
or other software components.
When HP PC Hardware Diagnostics (UEFI) detects a failure that requires hardware replacement, a 24-digit
Failure ID is generated. This ID can then be provided to support to help determine how to correct the problem.
To start HP PC Hardware Diagnostics (UEFI), follow these steps:
1. Turn on or restart the computer, and quickly press esc
2. Press F2.
The BIOS searches three places for the diagnostic tools, in the following order:
Using HP PC Hardware Diagnostics (UEFI) 73

HP Z240 Specifications

General

Chassis type	Tower
Product color	Black
Country of origin	China
Water cooling system	No
Product type	Workstation
Motherboard chipset	Intel® C236
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	64 GB
Memory layout (slots x size)	2 x 4 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	-
Total storage capacity	1000 GB
Number of HDDs installed	1
On-board graphics card ID	0x191D
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics P530
Graphics card Open GL support	Yes
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Power supply	400 W
Recovery operating system	Windows 10 Pro
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
Tcase	- °C
Bus type	DMI3
Stepping	R0
Processor cache	8 MB
Processor model	E3-1245V5
System bus rate	8 GT/s
Processor series	Intel Xeon E3-1200 v5
Processor socket	LGA 1151 (Socket H4)
Processor threads	8
Processor codename	Skylake
Processor frequency	3.5 GHz
Processor cache type	Smart Cache
Configurable TDP-down	- W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.9 GHz
PCI Express configurations	1x16, 1x8+2x4, 2x8
Thermal Design Power (TDP)	80 W
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Scalability	1S
Processor ARK ID	88173
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Secure Key Technology version	1.00

Weight and Dimensions

Depth	442 mm
Width	170 mm
Height	399 mm
Weight	8600 g
