HP Z240 User Manual

Chassis security
Smart Cover Sensor (optional)
The optional Smart Cover Sensor is a combination of hardware and software technology that alerts you when
the side panel of the computer is removed (provided the sensor has been congured in Computer Setup (F10)
Utility).
Three levels of protection are available *:
Level Setting Description
Level 0 Disabled
Sensor
*
is disabled (default).
Level 1 Notify User
When the computer restarts, a message indicates that the computer has been
o
pened or the access panel has been removed.
Level 2 Administrator Password
When the computer restarts, a message indicates that the computer has been
opened or the access panel has been removed. You must enter the administrator
password to continue.
*
Smart Cover Sensor settings are changed using Computer Setup (F10) Utility.
Setting the protection level
To set the Smart Cover Sensor protection level:
1
. Turn on or restart the computer.
2
. During startup, press and hold the F10 key until you enter Computer Setup (F10) Utility. Press enter to
bypass the title screen, if necessary.
NOTE: If you do not press the F10 key at the appropriate time, you must restart the computer, and
then pr
ess and hold the F10 key again to access Computer Setup (F10) Utility.
If you are using a PS/2 keyboard, you might see a keyboard error message. Disregard it.
3
. Select Security > Smart Cover > Cover Removal Sensor, and follow the on-screen instructions.
4
. Before exiting, select Main > Save Changes and Exit.
Side access panel solenoid lock
The side access panel solenoid lock (available only on specic workstations) secures the side access panel to
the chassis. The solenoid is controlled by a local or remote signal.
To lock the solenoid, set a password for the solenoid lock in Computer Setup (F10) Utility. To unlock the
solenoid, remove the solenoid lock password in Computer Setup (F10) Utility.
The solenoid lock FailSafe Key (available from HP) is is a device for manually disabling the solenoid lock. You
will need the FailSafe Key in case of a forgotten password, power loss, or computer malfunction.
Cable lock (optional)
To prevent theft, you can attach a keyed cable lock to the rear chassis panel. This cable lock attaches to the
chassis and secures it to the work area.
Fault notication and recovery
Fault notication
and recovery features combine innovative hardware and software technology to prevent the
loss of critical data and minimize unplanned downtime.
Desktop management 39

HP Z240 Specifications

General

Chassis type	Tower
Product color	Black
Country of origin	China
Water cooling system	No
Product type	Workstation
Motherboard chipset	Intel® C236
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	64 GB
Memory layout (slots x size)	2 x 4 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	-
Total storage capacity	1000 GB
Number of HDDs installed	1
On-board graphics card ID	0x191D
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics P530
Graphics card Open GL support	Yes
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Power supply	400 W
Recovery operating system	Windows 10 Pro
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
Tcase	- °C
Bus type	DMI3
Stepping	R0
Processor cache	8 MB
Processor model	E3-1245V5
System bus rate	8 GT/s
Processor series	Intel Xeon E3-1200 v5
Processor socket	LGA 1151 (Socket H4)
Processor threads	8
Processor codename	Skylake
Processor frequency	3.5 GHz
Processor cache type	Smart Cache
Configurable TDP-down	- W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.9 GHz
PCI Express configurations	1x16, 1x8+2x4, 2x8
Thermal Design Power (TDP)	80 W
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Scalability	1S
Processor ARK ID	88173
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Secure Key Technology version	1.00

Weight and Dimensions

Depth	442 mm
Width	170 mm
Height	399 mm
Weight	8600 g
