HP Z240 User Manual

Removal and replacement tips
●
To verify the type, size, and capacity of the storage devices installed in the computer, run Computer
Setup (F10) Utility.
●
Adding a new drive may require that you make new connections from the drive to the system board.
Note that:
◦
The primary Serial ATA (SATA) hard drive must be connected to the dark blue primary SATA
connector on the system board labeled SATA0.
◦
Connect a secondary hard drive to SATA1.
◦
Connect SATA optical drives to the black SATA2 connector.
◦
Connect an optional eSATA adapter cable to the black ESATA connector SATA3 on the system board.
(Tower only)
◦
Connect a media card reader USB cable to the USB connector on the system board labeled MEDIA. If
the media card reader has a 1394 port, connect the 1394 cable to the 1394 PCI card.
Drive installation and cabling scenarios
This section presents cabling guidelines for the most common maximum storage congurations. If you add or
remove drives, HP recommends you follow these guidelines for highest drive performance and ecient cable
routing.
SFF workstations—SATA cable connection guidelines
Conguration / PCA
SATA connector
SATA 0 SATA 1 SATA 2 SATA 3
HDD x1 ODD x1 1st HDD 1st ODD
HDD x2 ODD x1 1st HDD 2nd HDD 1st ODD
HDD x3 ODD x1 1st HDD 2nd HDD 1st ODD 3rd HDD
Tower workstations—SATA cable connection guidelines
Conguration / PCA SATA
connector
SATA 0 SATA 1 SATA 2 SATA 3
HDD x1 ODD x1 1st HDD 1st ODD e-SATA
HDD x1 ODD x2 1st HDD 1st ODD 2nd ODD
HDD x2 ODD x1 1st HDD 2nd HDD 1st ODD e-SATA
HDD x2 ODD x2 1st HDD 2nd HDD 1st ODD 2nd ODD
HDD x3 ODD x1 1st HDD 2nd HDD 1st ODD 3rd HDD
52 Chapter 3 Component replacement information and guidelines

HP Z240 Specifications

General

Chassis type	Tower
Product color	Black
Country of origin	China
Water cooling system	No
Product type	Workstation
Motherboard chipset	Intel® C236
Memory slots	4x DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	64 GB
Memory layout (slots x size)	2 x 4 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	-
Total storage capacity	1000 GB
Number of HDDs installed	1
On-board graphics card ID	0x191D
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics P530
Graphics card Open GL support	Yes
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Power supply	400 W
Recovery operating system	Windows 10 Pro
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
Tcase	- °C
Bus type	DMI3
Stepping	R0
Processor cache	8 MB
Processor model	E3-1245V5
System bus rate	8 GT/s
Processor series	Intel Xeon E3-1200 v5
Processor socket	LGA 1151 (Socket H4)
Processor threads	8
Processor codename	Skylake
Processor frequency	3.5 GHz
Processor cache type	Smart Cache
Configurable TDP-down	- W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.9 GHz
PCI Express configurations	1x16, 1x8+2x4, 2x8
Thermal Design Power (TDP)	80 W
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
Memory clock speeds supported by processor	1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Scalability	1S
Processor ARK ID	88173
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Secure Key Technology version	1.00

Weight and Dimensions

Depth	442 mm
Width	170 mm
Height	399 mm
Weight	8600 g
