HP Z32k G3 User Manual

2. To set the external monitor as the primary monitor, select Second screen only.
or
To set the external monitor as an extension of the primary monitor, select Extend.
or
To set the external monitor as a copy of the primary monitor, select Duplicate.
USB Type-C mode
When a Thunderbolt or USB Type-C cable is connected to the computer and Alt mode is detected, the monitor
switches to the USB Type-C mode and the following features are activated.
■
Connect a Thunderbolt or USB Type-C cable to activate the following features in USB Type-C mode.
● PXE boot
● MAC address pass through: Your computer might support MAC Address Pass Through from the on, o,
sleep, or hibernation states, or only when the computer is on or in the sleep state.
The MAC Address Pass Through is supported for UEFI PXE boot.
● Wake on LAN (WOL): Your computer might support WOL from the o, sleep, or hibernation states, or
only when the computer is on or in the sleep state.
WLAN-LAN switching is supported only on select computers running the Windows 10 operating
system.
Connect one end of the network cable to the RJ-45 (network) jack on the monitor and connect the
other end to an RJ-45 wall jack or router.
● Single power on: Pressing the monitor power button can also turn on power to the computer.
Updating the monitor
This section describes how to download and update the rmware for the monitor.
Downloading the HP
rmware installer
To download the HP rmware installer, follow this procedure:
1. Go to http://www.hp.com/support.
2. Select Get software and drivers, and follow the on-screen instructions to nd your monitor.
3. Follow the on-screen instructions to select and download the HP rmware installer.
4. Complete the installation wizard.
Updating
rmware for the monitor
To update the monitor rmware while connected to your computer:
1. Open Windows Explorer and navigate to where you saved the HP rmware installer.
2. Double-click to execute the installer le.
26
Chapter 3Using the monitor

HP Z32k G3 Specifications

General

Color depth	10 bit
Pixel pitch	0.18 x 0.18 mm
Screen shape	Flat
Pixel density	140 ppi
Backlight type	Edge LED
Display diagonal	31.5 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	29 - 60 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 135 kHz
sRGB coverage (typical)	100 %
Display bezel technology	Micro-Edge
Display number of colors	1.07 billion colors
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 3840 x 2160
Pivot angle	-90 - 90 °
Number of OSD languages	11
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR, RUS
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	180 W
Power consumption (standby)	0.5 W
Power consumption (typical)	35 W
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, DisplayPort, HDMI, Thunderbolt, USB Type-A to USB Type-B
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.4
USB upstream port type	USB Type-B, USB Type-C
USB Power Delivery up to	100 W
USB Type-A downstream ports quantity	4
Sustainability certificates	ENERGY STAR
HP segment	Business
Package depth	185 mm
Package width	816 mm
Package height	504 mm
Package weight	13700 g
Product color	Black, Silver

Weight and Dimensions

Depth (with stand)	217 mm
Width (with stand)	713.5 mm
Height (with stand)	604.9 mm
Weight (with stand)	9000 g
Depth (without stand)	47 mm
Height (without stand)	415.9 mm
