HP Z32k G3 User Manual

Technical specicationsA
This section contains technical specications for the physical aspects of your monitor, such as the weight and
viewing dimensions, as well as required environmental operating conditions and power source ranges.
All specications represent the typical specications provided by HP component manufacturers; actual
performance can vary either higher or lower.
NOTE: For the latest specications or additional specications for this product, go to
http://www.hp.com/go/quickspecs/ and search for your specic monitor model to nd the model-specic
QuickSpecs.
80 cm (31.5 in) model
specications
This section provides specications for your monitor.
Table A-1 Technical specications
Specication Measurement
Display, wide-screen 80 cm 31.5 in
Type IPS
Viewable image size 80 cm diagonal 31.5 in diagonal
Maximum weight (unpacked) 9.0 kg 19.8 lbs
Dimensions (include base)
Height (highest position) 60.49 cm 23.81 in
Height (lowest position) 45.49 cm 17.91 in
Depth 21.70 cm 8.54 in
Width 71.35 cm 28.09 in
Tilt –5° to 20°
Swivel +/- 45°
Pivot +/- 90°
Environmental requirements temperature
Operating temperature 5°C to 35°C 41°F to 95°F
Storage temperature –20°C to 60°C –4°F to 140°F
Storage humidity 5% to 95% (noncondensing)
Power source 100 V ac to 240 V ac 50/60 Hz
Input terminal One HDMI port, one DisplayPort connector, one USB Type-B connector, and one
Thunderbolt connector
32 Appendix ATechnical specications

HP Z32k G3 Specifications

General

Color depth	10 bit
Pixel pitch	0.18 x 0.18 mm
Screen shape	Flat
Pixel density	140 ppi
Backlight type	Edge LED
Display diagonal	31.5 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	29 - 60 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 135 kHz
sRGB coverage (typical)	100 %
Display bezel technology	Micro-Edge
Display number of colors	1.07 billion colors
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 3840 x 2160
Pivot angle	-90 - 90 °
Number of OSD languages	11
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR, RUS
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	180 W
Power consumption (standby)	0.5 W
Power consumption (typical)	35 W
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, DisplayPort, HDMI, Thunderbolt, USB Type-A to USB Type-B
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.4
USB upstream port type	USB Type-B, USB Type-C
USB Power Delivery up to	100 W
USB Type-A downstream ports quantity	4
Sustainability certificates	ENERGY STAR
HP segment	Business
Package depth	185 mm
Package width	816 mm
Package height	504 mm
Package weight	13700 g
Product color	Black, Silver

Weight and Dimensions

Depth (with stand)	217 mm
Width (with stand)	713.5 mm
Height (with stand)	604.9 mm
Weight (with stand)	9000 g
Depth (without stand)	47 mm
Height (without stand)	415.9 mm
