Page #6 background image
Getting started1
Read this chapter to learn about safety information and where to nd additional HP resources.
Important safety information
An AC power cord is included with the monitor. If you use another cord, use only a power source and
connection appropriate for this monitor. For information about the correct power cord set to use with the
monitor, see the Product Notices provided in your documentation kit.
WARNING! To reduce the risk of electric shock or damage to the equipment:
Plug the power cord into an AC outlet that is easily accessible at all times.
If the power cord has a three-pin attachment plug, plug the cord into a grounded (earthed) three-pin
outlet.
Disconnect power from the computer by unplugging the power cord from the AC outlet. When
unplugging the power cord from the AC outlet, grasp the cord by the plug.
For your safety, do not place anything on power cords or cables. Take care to route all cords and cables
connected to the monitor so that they cannot be stepped on, pulled, grabbed, or tripped over.
To reduce the risk of serious injury, read the Safety & Comfort Guide provided with your user guides. It
describes proper workstation setup and proper posture, health, and work habits for computer users. The
Safety & Comfort Guide also provides important electrical and mechanical safety information. The Safety &
Comfort Guide is also available on the web at http://www.hp.com/ergo.
IMPORTANT: For the protection of the monitor and the computer, connect all power cords for the computer
and its peripheral devices (such as a monitor, printer, scanner) to a surge protection device such as a power
strip or uninterruptible power supply (UPS). Not all power strips provide surge protection; the power strip
must be specically labeled as having this capability. Use a power strip whose manufacturer oers a damage
replacement policy so that you can replace the equipment if surge protection fails.
Use the appropriate and correctly sized furniture designed to properly support your monitor.
WARNING! Monitors that are inappropriately situated on dressers, bookcases, shelves, desks, speakers,
chests, or carts could fall over and cause personal injury.
WARNING! Stability hazard: The device might fall, causing serious personal injury or death. To prevent
injury, securely attach the monitor to the oor or wall in accordance with the installation instructions.
WARNING! This equipment is not suitable for use in locations where children are likely to be present.
NOTE: This product is suitable for entertainment purposes. Consider placing the monitor in a controlled
luminous environment to avoid interference from surrounding light and bright surfaces that might cause
disturbing reections from the screen.
Getting started
1

Table of Contents

Other manuals for HP Z32k G3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Z32k G3 and is the answer not in the manual?

HP Z32k G3 Specifications

General IconGeneral
Color depth10 bit
Pixel pitch0.18 x 0.18 mm
Screen shapeFlat
Pixel density140 ppi
Backlight typeEdge LED
Display diagonal31.5 \
Surface hardness3H
Anti-glare screenYes
Display technologyLCD
Native aspect ratio16:9
Vertical scan range29 - 60 Hz
Maximum refresh rate60 Hz
Horizontal scan range30 - 135 kHz
sRGB coverage (typical)100 %
Display bezel technologyMicro-Edge
Display number of colors1.07 billion colors
Display brightness (typical)400 cd/m²
Supported graphics resolutions640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 3840 x 2160
Pivot angle-90 - 90 °
Number of OSD languages11
Panel mounting interface100 x 100 mm
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR, RUS
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (max)180 W
Power consumption (standby)0.5 W
Power consumption (typical)35 W
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)20 - 80 %
Cables includedAC, DisplayPort, HDMI, Thunderbolt, USB Type-A to USB Type-B
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports1
USB hub version3.2 Gen 1 (3.1 Gen 1)
DisplayPort version1.4
USB upstream port typeUSB Type-B, USB Type-C
USB Power Delivery up to100 W
USB Type-A downstream ports quantity4
Sustainability certificatesENERGY STAR
HP segmentBusiness
Package depth185 mm
Package width816 mm
Package height504 mm
Package weight13700 g
Product colorBlack, Silver
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)217 mm
Width (with stand)713.5 mm
Height (with stand)604.9 mm
Weight (with stand)9000 g
Depth (without stand)47 mm
Height (without stand)415.9 mm
