Figure 10-36 Entering the BIOS password
Step 6 Enter the BIOS password.
● The default BIOS password is Admin@9000.
● Press F2 to alternate between the English (US), French, and Japanese keyboards.
● For security purposes, change the administrator password periodically.
● The system will be locked if an incorrect password is entered three consecutive times.
You can restart the server node to unlock it.
The Main screen of the Setup Utility program is displayed.
----End
10.6.2 Accessing the BIOS (V6XX or Later)
Procedure
Step 1 Log in to the desktop of the server node.
For details, see 10.3 Logging In to the Desktop of a Server.
Step 2 On the Remote Virtual Console, click
on the menu bar.
Step 3 Choose Forced System Reset or Forced Power Cycle.
The Select an Option dialog box is displayed.
FusionServer Pro XH321 V5 Server Node
Maintenance and Service Guide 10 Common Operations
Issue 17 (2021-03-09) Copyright © Huawei Technologies Co., Ltd. 146
