For details, see "Avago SAS3004iMR > Troubleshooting > Hard Drive Fault" in
Huawei V5 Server RAID Controller Card User Guide
.
----End
8.4.11 Removing a Processor
● Only Huawei technical support or personnel authorized by Huawei can remove
the processors from Huawei servers.
● Do not wear ESD gloves during processor replacement. The gloves may catch
on pins on the processor socket and damage it.
Procedure
Step 1 Power o the server node.
For details, see 8.3.2 Power-O Procedure.
Step 2 Remove the server node.
For details, see 8.3.3 Removing an XH321 V5.
Step 3 Place the server node on the ESD workstation.
Step 4 Remove the air duct.
For details, see 8.4.23 Removing the Air Duct.
Step 5 Determine the position of the processor.
Figure 8-29 Positions of processors
FusionServer Pro XH321 V5 Server Node
Maintenance and Service Guide 8 Parts Replacement
Issue 17 (2021-03-09) Copyright © Huawei Technologies Co., Ltd. 66
