Step 9 Install the air duct for the supercapacitor.
Step 10 Install the server node.
For details, see 8.3.4 Installing an XH321 V5.
Step 11 Power on the server node.
For details, see 8.3.1 Power-On Procedure.
----End
8.4.7 Removing the Avago SAS3004iMR PCIe RAID Controller
Card
Procedure
Step 1 Power o the server node.
For details, see 8.3.2 Power-O Procedure.
Step 2 Remove the server node.
For details, see 8.3.3 Removing an XH321 V5.
Step 3 Place the server node on the ESD workstation.
Step 4 Determine the position of the Avago SAS3004iMR RAID controller card.
Step 5 Remove the M.2 FRU from the Avago SAS3004iMR RAID controller card.
For details, see 8.4.9 Removing an M.2 FRU on the Avago SAS3004iMR PCIe
RAID Controller Card.
Step 6 Remove the Avago SAS3004iMR RAID controller card.
For details, see 8.4.19 Removing a PCIe Card.
Step 7 Place the removed component in an ESD bag.
Place only one component in an ESD bag.
----End
8.4.8 Installing the Avago SAS3004iMR PCIe RAID Control
Card
Procedure
Step 1 Power
o the server node.
For details, see 8.3.2 Power-O Procedure.
FusionServer Pro XH321 V5 Server Node
Maintenance and Service Guide 8 Parts Replacement
Issue 17 (2021-03-09) Copyright © Huawei Technologies Co., Ltd. 61
