Huawei OceanStor S2600 Routine Maintenance

Table 3-5 Description of the indicators on the front panel
Module Indicator Color Status Description
System
enclosure
Power
indicator of
the disk
enclosure
Green On The disk enclosure is powered on.
- Off The disk enclosure is not powered
on or no alarm is generated.
Startup/
alarm
indicator of
the disk
enclosure
Red On The disk enclosure is out of service
or an alarm is generated on the disk
enclosure.
NOTE
If the indicator is red for a long time,
the system encounters an emergent
fault.
Red
Turns on,
and then
turns off
three
seconds
later; turns
on again, and
then turns off
after the disk
enclosure is
normally
started.
The disk enclosure is being started.
- Off The disk enclosure is working
normally.
Disk
module
Disk running
indicator
Green Blinking Data is being transmitted from or to
the disk.
Green On The disk is powered on normally.
- Off The disk is not powered on or
powered on abnormally.
Disk alarm/
location
indicator
- Off The disk is powered on normally.
Red On An alarm is generated on the disk.
Red Blinking The disk is located.
The indicators on the rear panel of the D120S disk enclosure are shown in Table 3-6.
