Huawei RRU3804 User Manual

2.1.3 LEDs on the RRU3804
The LEDs, on the LED panel of the RRU3804, indicate the running status of the RRU3804.
For the positions of the LEDs on the RRU3804, refer to 2.1.5 Panels of the RRU3804.
Table 2-1 describes the LEDs and their status.
Table 2-1 LEDs on the RRU3804
Label Color Status Description
RUN Green ON The module has power input,
yet the module is faulty.
OFF The module has no power input
or is reporting alarms.
1s ON, 1s OFF The module is operational.
0.5s ON, 0.5s OFF Software is being loaded to the
module.
ALM Red ON The module is reporting alarms
(excluding VSWR-related
alarms).
OFF The module is operational.
TX_ACT Green ON The module is running.
OFF No specific meaning
VSWR Red ON VSWR-related alarms are
reported.
OFF No VSWR-related alarm is
reported.
CPRI_W Red/green ON (green) The CPRI link is normal.
ON (red) The optical module receives
local alarms related to LOS.
0.5s ON, 0.5s OFF
(red)
The CPRI link is out of lock.
OFF The optical module is not in
position or is powered off.
CPRI_E Red/green ON (green) The CPRI link is normal.
ON (red) The optical module receives
local alarms related to LOS.
0.5s ON, 0.5s OFF
(red)
The CPRI link is out of lock.
2 RRU3804 and SRXU Hardware
RRU3804
User Guide
2-6 Huawei Technologies Proprietary Issue 01 (2007-11-29)
