Instruments Multimeter, 500 V megohmmeter (for insulation resistance), BER tester,
optical power meter
NOTE
The instruments must be checked and certified.
3.4 Installing the RRU3804 on the Ground or Rooftop
When the RRU3804 needs to be installed on the ground or rooftop, it supports one-module, two-
module centralized, and three-module centralized installation modes.
3.4.1 Installing a Single RRU3804
This describes how to install a single RRU3804 module and its mounting plate. The single
RRU3804 can be installed on a metal pole or wall.
3.4.2 Installing Two RRU3804s
This describes how to install two RRU3804 modules and their mounting plates. The two
RRU3804s can be installed on a metal pole or wall.
3.4.3 Installing Three RRU3804s
This describes how to install three RRU3804 modules and their mounting plates. The three
RRU3804s can be installed on a metal pole or wall.
3.4.1 Installing a Single RRU3804
This describes how to install a single RRU3804 module and its mounting plate. The single
RRU3804 can be installed on a metal pole or wall.
Procedure
Step 1 Install the mounting plate of the RRU3804. The operation varies with the installation mode.
Condition
Action
The RRU3804 needs to be installed on a
metal pole.
Install the mounting plate of the single
RRU3804 on the metal pole.
The RRU3804 needs to be installed on a wall. Install the mounting plate of the single
RRU3804 on the wall.
Step 2 Install the single RRU3804 module. For details, refer to 3.4.1.3 Installing the Single RRU3804
Module.
----End
Installing the Mounting Plate of the Single RRU3804 on the Metal Pole
This describes how to install the mounting plate on the metal pole.
3 Installing RRU3804 and SRXU Hardware
RRU3804
User Guide
3-14 Huawei Technologies Proprietary Issue 01 (2007-11-29)
