13
Touch Screen Overview
TOUCH SCREEN OVERVIEW (CROSS TOUCH MODELS ONLY)
A
summary of the touch screen actions are shown here. The touch screen actions are also determined by the view displayed on the
s
creen.
TAP OR PRESS AND HOLD
Select a View, Tool, Menu, or Icon: Tap the
selection once.
Activate the Cursor: Tap a position on the
view. Press and hold a position to open the
Cursor menu.
Zoom In: Tap the screen twice.
PINCH IN/OUT
Zoom In: Touch the screen with two fingers
and move them apart.
Zoom Out: Touch the screen with two fingers
and bring them closer together.
SWIPE SIDE TO SIDE
Next/Previous: With a Favorites View
displayed on-screen, swipe (left or right) to
view the next or previous view available.
SWIPE DOWN
Home Screen/View Toggle: With a view
displayed on-screen, touch the screen with
two fingers and swipe down to go to the
Home Screen. To return to the previous view,
swipe down with two fingers again.
TWO FINGER TAP
Switch to 2D or 3D View: With a 2D Chart
View displayed on-screen, tap twice to
switch to 3D or back to 2D (Navionics and
C-MAP by Jeppesen only. See Customize the
Chart View).
Zoom Out: Tap the screen twice.
ONE FINGER SWIPE
UP OR DOWN
Browse Menus: Swipe with one finger to
scroll through a menu list (up or down).
ONE FINGER SWIPE
LEFT OR RIGHT
Adjust Menu Slider: Tap the menu to select
it. Drag the slider to adjust the setting.
See More: Swipe the Favorites View bar and
the Tools bar to browse through the icons on
the Home screen.
Pan: With a Chart View displayed on the
screen, drag one finger across the screen to
see more of the chart that is displayed
off-screen. With a 2D Sonar View displayed
on the screen, drag one finger across the
screen to see more of the sonar history.
