INSTALLATION INFORMATION
T
his section includes information that may be required to connect new equipment or a new accessory to the control head. There
a
re several configurations available for your ONIX and ION control head. You can network control heads, connect accessories to an
E
thernet network, connect to a NMEA 2000 network, and add transducers to your system through black box sonar. For configuration
o
ptions and the latest Humminbird accessories, visit our Web site at humminbird.com.
Installation guides are included with each hardware component to install equipment purchased separately (transducer, heading
sensor, radar, AIS, autopilot, and accessories). See your installation guides for details.
Unused Ports: Any unused ports should be covered with the port covers to prevent potential damage to the control head.
Cables: We also recommend that you label the cables with waterproof tags for future reference.
WARNING! Before you connect cables to the control head, or disconnect cables, the control head power and equipment power
sources must be turned off.
CAUTION! Before you update the control head software, synchronize units on the network, or restore system defaults, export
your control head menu settings to an SD card. It is also recommended to export your navigation data to an SD card. See Update
Software for details.
NOTE: If you have questions about the installation or troubleshooting, see your control head installation guide. Also, contact
Humminbird Customer Service at humminbird.com.
