70
Chart Options
CHANGE THE CHART VIEW OVERLAYS
U
se the Overlays menu to display or hide information on the view. In a Chart View, you can display or hide the vessel icon, navigation
d
ata (waypoints, routes, tracks), data overlays, AIS and MARPA targets, and range rings. The available menu options are determined
b
y the accessories attached to the control head network. Also, see Views for more information about Overlays.
1. With a Chart View displayed on-screen, tap Chart in the status bar, or press the MENU key once.
2. Select Chart Options.
3. Select Overlays.
4. Use the touch screen or Joystick to select a menu and change a setting. (check mark = visible, blank = hidden).
map scale
track
waypoint
saved route
route point
Chart View with Overlays Displayed (Humminbird)
north
indicator
compass icon
heading line
boat icon
